Cooker with Gas Hob
90x60 cm Portofino Aesthetic

Features Energy consumption Dimensions
R62 999,00
R62 999,00
Product code: CPF9GPX
Compact-design cooker with electric oven and gas hob: efficient and responsive, the visible heat source allows total control and choice of the right intensity.
  • The best cooking performances guaranteed by ventilated circular flow - True-convection
  • Induction offers fast cooking and precise temperature control - Gas hob
  • The best cooking performance at the highest energy efficiency
  • The oven has three fans and two circular heating elements, allowing cooking with rotating heat
  • New cooling system with tangential fan and airflow from the door to the splashback
  • The door is equipped with a specific system for silent closing
  • Easy oven cleaning thanks to special pyrolytic function
  • Highlights
  • Features
  • Accessories
  • Download
Ever Clean Enamel

Ever Clean Enamel

Smeg’s unique anti-acid Ever Clean enamel facilitates the oven cleaning process, decreasing the adhesion of fats to the walls courtesy of the reduced porosity of the surface, with glossy smooth finish

Electronic Display

Electronic Display

A large, intuitive LCD interface to achieve the highest levels of accuracy, by precisely monitoring all the parameters set. The display also provides access to 20 automatic cooking programs, introducing users to the world of professional cooking.

Soft Close Door

Soft Close Door

All Smeg gas cooktops are designed to increase and reduce the flame incrementally to provide the optimum control for cooking from low simmer to full power for a rolling boil.

Pyrolitic perfection: effortless cleaning

With pyrolysis, a self-cleaning process at 500°C, maximum hygiene is achieved, without the need for chemicals, thanks to the simple power of heat, effortlessly for an always impeccable kitchen.

Aesthetics

Heavy duty cast iron pan stands: for maximum stability and strength. Knobs control With a simple and intuitive interface, the COMPACTscreen provides a pleasant user experience, thanks to the interaction with the knobs. Fingerprint proof stainless steel: Fingerprint proof stainless steel keeps stainless steel looking as good as new.
Design: Flush fit
Command panel finish: Finger friendly stainless steel
Aesthetic: Portofino
Material: Stainless steel
Colour: Stainless steel
Finishing: Satin
Upstand: Yes
Hob colour: Stainless steel
Type of pan stands: Cast Iron
Type of control setting hob: Control knobs
Control knobs: Smeg Portofino
Controls colour: Stainless steel
No. of controls: 8
Display: CompactScreen
Door: With frame
Glass type: Grey
Handle: Smeg Portofino
Handle Colour: Brushed stainless steel
Storage compartment: Push pull
Feet: Black
Plinth: Black

Type

Installation in column: Installation in column PYROLYSIS - AUTOMATIC CLEANING FUNCTION: the oven heats up to a temperature approaching 500 ° C and chars grease and food residues into a fine ash that can be easily wiped off with a damp cloth. At such a high temperature, the door locks automatically for safety, while the temperature of the door remains controlled so it is safe to touch User adjustable function based on the level of dirt present in the oven.
Product Family: Cooker
Cooker size: 90x60 cm
Cooker configuration: Dual fuel
Hob type: Gas
Hob energy type: Gas
N. of ovens: 1
Type of main oven: Thermo-ventilated
EAN code: 8017709225780
Installation positioning of the appliance: Free-standing, Class 1, Built-in, Class 2-1 norm UNI EN 30-1-1
Cleaning system: Pyrolitic

Programs / Functions

Automatic programs: 20
Other functions
  • Defrost by time: Manual defrost function. At the end of the set duration, the function stops. Defrost by time
  • Defrost by weight: Automatic defrost function. You choose the type of food to defrost from the available categories (MEAT - FISH - BREAD - DESSERTS) After entering the weight of the food, the oven automatically defines the time required for proper defrosting. Defrost by weight
  • Air at 40°C provides the perfect environment for proving yeast type dough mixes. Simply select the function and place dough in the cavity for allotted Proving
  • SABBATH: function that allows to cook food respecting Judaism's day of rest provisions. Sabbath
Traditional cooking functions
  • Static: Traditional cooking suitable for the preparation of one dish at a time. The fan is not active and the heat comes from below and from above at the same time. Static cooking is slower and more delicate, ideal in order to get well cooked and dry dishes even inside. Ideal for cooking all types of roasts, fatty meats, bread, filled cakes. Static
  • Fan assisted: Intense and homogeneous traditional cooking, also suitable for complex recipes. The fan is active and the heat comes from below and from above at the same time. Ventilated cooking ensures a faster and more homogeneous result, leaving fragrant foods outside and moister inside. Ideal for baked pasta, biscuits, roasts and cobblers. Fan assisted
  • Circulaire: it is the perfect function for cooking all types of dishes in a more delicate way. The heat comes from the back of the oven and is distributed quickly and evenly The fan is active. It is also ideal for cooking on multiple levels without mixing smells and flavors. Circulaire
  • Turbo: the heat comes from 3 directions: above, below and from the back of the oven The fan is active. It allows quick cooking, even on several shelves without mixing the aromas. Ideal for large volumes or foods that require intense cooking. Turbo
  • ECO: low energy consumption cooking: this function is particularly suitable for cooking on a single shelf with low energy consumption. It is recommended for all types of food except those that can generate a lot of moisture (for example vegetables). To achieve maximum energy savings and reduce time, it is recommended to put the food in the oven without preheating the cooking compartment Eco
  • Half grill: For rapid cooking and browning of foods. Best results can be obtained by using the top shelf for small items, the lower shelves for larger ones, such as chops or sausages. For half grill heat is generated only at the centre of the element, so is ideal for smaller quantities. Small grill
  • Grill: Very intense heat coming only from above from a double heating element. The fan is not active. Provides excellent grilling and gratinating results. Used at the end of cooking, it gives a uniform browning to dishes. Large grill
  • Fan grill: very intense heat coming only from above from a double heating element The fan is active. It allows the optimal grilling of thickest meats. Ideal for large cuts of meat. Fan grill (large)
  • Base: the heat comes only from the bottom of the cavity. The fan is not active. Ideal for sweet and savory pies, cobblers and pizzas. Designed to complete cooking and make food more crunchy This symbol in gas ovens indicates the gas burner. Base
  • Fan assisted base: the mix of fan and lower heating element alone allows to finish cooking foods already cooked on the surface but not internally more quickly. This system is recommended to finish cooking foods that are already well cooked on the surface, but not internally, which therefore require a moderate higher heat. Ideal for any type of food. Fan assisted base
Cleaning functions
  • PYROLYSIS - AUTOMATIC CLEANING FUNCTION: the oven heats up to a temperature approaching 500 ° C and chars grease and food residues into a fine ash that can be easily wiped off with a damp cloth. At such a high temperature, the door locks automatically for safety, while the temperature of the door remains controlled so it is safe to touch User adjustable function based on the level of dirt present in the oven. Pyrolytic
  • Pyrolitic: The Eco pyrolitic cleaning function can be selected when the oven has a lighter build up of dirt. This function has a maximum duration of 1.5 hours. Pyrolytic eco

Options Main Oven

Timer: Yes
End of cooking acoustic alarm: Yes
Minimum Temperature: 50 °C
Maximum temperature: 260 °C

Hob technical features

Ultra rapid burners: Powerful ultra rapid burners offer up to 5kw of power.
Total no. of cook zones: 6
1st zone position: Front left
2nd zone position: Rear left
3rd zone position: Front centre
4th zone position: Rear centre
5th zone position: Front right
6th zone position: Rear right
1st zone type: Gas - 2UR (dual)
2nd zone type: Gas - AUX
3rd zone type: Gas - AUX
4th zone type: Gas - Semi Rapid
5th zone type: Gas - Semi Rapid
6th zone type: Gas - Rapid
1st zone power: 4.20 kW
2nd zone power: 1.00 kW
3rd zone power: 1.00 kW
4th zone power: 1.80 kW
5th zone power: 1.80 kW
6th zone power: 3.00 kW
Type of gas burners: Standard
Burner caps: Matt black enamelled
Automatic electronic ignition: Yes
Gas safety valves: Yes

Main Oven Technical Features

Electronic control: Allows you to maintain temperature inside the oven with the precision 2-3 ° C. This enables to cook meals that are very sensitive to temperature changes, such as cakes, souffles, puddings. Triple Fan Technology: The oven is equipped with an exclusive three fan system, which, combined with the increased power of the motors, enables excellent cooking performance. The two large side fans distribute the air around the outer perimeter of the cavity while the smaller central fan increases ventilation by creating a vertical vortex of heat. Accordingly, the temperature within the cavity is uniform, allowing food to be cooked evenly on all five levels, like in professional kitchens. All glass inner door: All glass inner door, a single flat surface which is simple to keep clean. Air cooling system: to ensure a safe surface temperatures. Quadruple glazed: Number of glazed doors. The capacity indicates the amount of usable space in the oven cavity in litres. Ever Clean Enamel: Ever Clean enamel is applied electrostatically, corner to corner and edge to edge to prevent cracking or cracks over time. It is a particular pyrolytic enamel, resistant to acids which, in addition to being pleasantly bright, promotes greater cleaning of the oven walls, thanks to its lower porosity. It is baked at over 850 ° C and slowly polymerized at a scientifically determined rate to ensure uniform depth and strength Ever Clean enamel creates an impeccable finish both on the inside of the oven and on the trays, making the surfaces of the oven incredibly easy to maintain over time as it reduces the adhesion of fat during cooking Soft close: all models are equipped with advanced function of smooth closing of the door, which allows the device to close smoothly and quietly. The oven cavity has 5 different cooking levels. The inner door glass: can be removed with a few quick movements for cleaning. Side lights: Two opposing side lights increase visibility inside the oven.
Net volume of the cavity: 115 l
Gross volume, 1st cavity: 129 l
Cavity material: Ever Clean enamel
No. of shelves: 5
Type of shelves: Metal racks
No. of lights: 2
Light type: Halogen
Light Power: 40 W
Fan number: 3
Cooking time setting: Start and Stop
Door opening: Flap down
Light when oven door is open: Yes
Removable door: Yes
Full glass inner door: Yes
Removable inner door: Yes
Total no. of door glasses: 4
No.of thermo-reflective door glasses: 3
Door Lock During Pyrolisis: Yes
Safety Thermostat: Yes
Cooling system: Tangential
Heating suspended when door is opened: Yes
Grill type: Electric
Grill elememt: 1700 W
Large grill - Power: 2900 W
Lower heating element power: 1700 W
Upper heating element - Power: 1200 W
Circular heating element - Power: 2 x 1850 W
Soft Close system: Yes
Temperature control: Electronic

Performance / Energy Label

???Class_Arrows_A+++D_A+???
Energy efficiency class: A+
Energy consumption in forced air convection: 5.22 MJ
Energy consumption per cycle in fan-forced convection: 1.45 kWh
Energy consumption in conventional mode: 3.02 MJ
Energy consumption per cycle in conventional mode: 0.84 kWh

Electrical Connection

Electrical connection rating: 4000 W
Current: 18 A
Voltage: 220-240 V
Voltage 2 (V): 380-415 V
Frequency: 50/60 Hz
Plug: Not present
Additional connection modalities: Yes, Double and Three Phase
Installed electric cable: Yes, Single phase

Gas Connection

Gas connection rating (W): 12500 W
Gas Type: G20 Natural gas

Standby consumption

Standby activation time: 2 min
Standby power: 0.6 W
Show information in Standby: Yes

Logistic Information

Dimensions of the product HxWxD (mm): 900x900x600 mm
Width (mm): 900 mm
Product Height (mm): 900 mm
Depth (mm): 600 mm
Dimensions of the packed product (mm): 860x960x670 mm
Gross weight (kg): 105.700 kg
Net weight (kg): 95.800 kg
Packed width: 960 mm
Packaged depth: 670 mm
Height (mm) packed: 860 mm
Type of packaging: Shrinkwrap
Packaging composition - paper & cardboard (kg): 4.858 kg
Packaging composition - polystyrene (kg): 1.447 kg
Packaging composition - wood (kg): 2.660 kg
Packaging composition - plastic (kg): 0.956 kg

Accessories included for Main Oven & Hob

Rack with back and side stop: 1
Grill mesh: 1
20mm deep tray: 1
40mm deep tray: 1
Telescopic Guide rails, partial Extraction: 1

Accessories Included

Other gas nozzles included: G30 LPG liquid gas

Optional

PALPZ
PALPZ
R949,00
R949,00
Accessories | Type: Pizza shovel | Ovens | Cookers
GTT
GTT
R1 099,00
R1 099,00
Accessories | Type: Telescopic Guides | Ovens | Cookers

Technical drawing

Download (png)

Instruction manual

User manual (EN) (pdf)
Other Instructions (ALL) (pdf)

Warranty

Warranty certificate (EN) (pdf)

Product sheet

Download

3D file

Download
