Decorative wall hood

150 cm Classica Aesthetic

Energy consumption Dimensions

R26 999,00

R26 999,00

Where to buy

Compare

Product code: KD150HXE

Highlights
Features
Accessories
Download

Intensitive function

Intensitive function

The intensive function allows to operate the hood at maximum power, to speed up the elimination of the most persistent odors and to have a purified environment.

Aesthetics

Aesthetic: Classica

Colour: Stainless steel

Design: Chimney

Finishing: Satin

Material: Stainless steel

Type of steel: Brushed

Program / Functions

No. of speeds: 3

Intensive speed: Yes

Type

Product family: Hood

Hood Type: Decorative wall hood

Hood width: 150 cm

Extraction: Extraction

EAN code: 8017709276898

Technical Features

No. of lights: 4

Light type: LED

Light Power: 1 W

Light color temperature scale (K): 4000 K

Free outlet maximum capacity: 830 m³/h

Motor power: 275 W

No. of filters: 5

Anti-grease filters: Stainless steel

Minimum distance from GAS hob: 750 mm

Minimum distance from ELECTRIC hob: 650 mm

Vent outlet: 150 mm

Non return valve: Yes

Controls

Control setting: Control knobs

Control knobs: Classic

No. of controls: 2

Controls colour: Steel effect

Performance / Energy Label

Energy efficicency class ( EEC): A+

Fluid Dynamic Efficiency class (FDEC): A

Grease Filtering Efficiency Class (GFEC): D

Lighting Efficiency Class (LEC): A

Annual Efficiency Consumption (AEChood): 41 kWh/a

Fluid Dynamic Efficiency (FDE): 36

Lighting Efficiency (LE): 59.8 lux/W

Grease Filtering Efficiency (GFE): 71.3 %

Air flow at minumum speed (Qmin): 292 m³/h

Air flow at maximum speed (Qmax): 626 m³/h

Air flow at boost speed (Qboost): 787 m³/h

Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 49 dBA

Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 68 dBA

Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost): 72 dBA

Time increase factor (F): 0.7

Energy Efficiency Index: 41.3

Measured air flow rate at best efficiency point (Qbep): 382 m³/h

Measured air pressure at best efficiency point (Pbep): 496 Pa

Measured electric power input at best efficiency point (Wbep): 146 W

Nominal Power consumption of the light system (WL): 4 W

Average illumination of the light on the cooking surface (Emiddle): 263 lux

Sound power level at highest setting (Lwa): 68 dBA

Electrical Connection

Electrical connection rating: 279 W

Voltage: 220-240 V

Frequency (Hz): 50-60 Hz

Plug: Not present

Power supply cable length: 1000 mm

Speed 1

Extraction rate IEC 61591: 292 m³/h

Noise level IEC 60704-2-13: 49 dBA

Power: 167 W

Speed 2

Extraction rate IEC 61591: 415 m³/h

Noise level IEC 60704-2-13: 58 dBA

Power: 214 W

Speed 3

Extraction rate IEC 61591: 626 m³/h

Noise level IEC 60704-2-13: 67 dBA

Power: 244 W

Intensive speed

Extraction rate (IEC 61591): 787 m³/h

Noise level IEC 60704-2-13: 72 dBA

Power: 277 W

Logistic Information

Dimensions of the product (mm): 800x1500x539

Width: 1500 mm

Depth (mm): 539 mm

Product Height (mm): 800 mm

Net weight (kg): 26.530 kg

Gross weight (kg): 33.460 kg

Packed width: 1570 mm

Packaged depth: 525 mm

Height (mm) packed: 660 mm

Dimensions of the packed product (mm): 660x1570x525

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 5.638 kg

Packaging composition - polystyrene (kg): 0.870 kg

Packaging composition - wood (kg): 0.300 kg

Packaging composition - plastic (kg): 0.122 kg

Optional

KITALLFC

Accessories | Type: Charcoal filter | Hoods

Where to buy

FLT6

Accessories | Type: Charcoal filter | Hoods

Where to buy

Technical drawing

Instruction manual

User manual (EN) (pdf)

User manual (EN) (pdf)

Product sheet

Download
