Integrated (semi) hood

60 cm Universale Aesthetic

Energy consumption Dimensions

R3 099,00

R3 099,00

Where to buy

Compare

Product code: KTE60E2

Integrated hood, 60 cm, with visible style and clean lines, it integrates perfectly into the kitchen while staying visible for easy access to the display. It offers powerful and silent suction, ensuring a constantly odor-free environment.

Features
Accessories
Download

Aesthetics

Aesthetic: Universale

Colour: Stainless steel

Design: Visible front panel

Finishing: Satin

Components finishing: Stainless steel

Material: Stainless steel

Type of steel: Brushed

Program / Functions

No. of speeds: 3

Type

Product family: Hood

Hood Type: Integrated (semi) hood

Hood width: 60 cm

Extraction: Extraction

EAN code: 8017709333652

Technical Features

No. of lights: 2

Light type: LED

Light Power: 6 W

Light color temperature scale (K): 2700 K

Free outlet maximum capacity: 282 m³/h

Motor power: 95 W

No. of filters: 1

Anti-grease filters: Aluminium

Minimum distance from GAS hob: 650 mm

Minimum distance from ELECTRIC hob: 500 mm

Vent outlet: 125 mm

Controls

Control setting: Slider

Performance / Energy Label

Energy efficicency class ( EEC): D

Fluid Dynamic Efficiency class (FDEC): E

Grease Filtering Efficiency Class (GFEC): D

Lighting Efficiency Class (LEC): B

Annual Efficiency Consumption (AEChood): 55 kWh/a

Fluid Dynamic Efficiency (FDE): 9.2

Lighting Efficiency (LE): 20.1 lux/W

Grease Filtering Efficiency (GFE): 65.1 %

Air flow at minumum speed (Qmin): 125 m³/h

Air flow at maximum speed (Qmax): 265 m³/h

Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 50 dBA

Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 64 dBA

Time increase factor (F): 1

Energy Efficiency Index: 1.7

Measured air flow rate at best efficiency point (Qbep): 155 m³/h

Measured air pressure at best efficiency point (Pbep): 175 Pa

Measured electric power input at best efficiency point (Wbep): 82 W

Nominal Power consumption of the light system (WL): 6 W

Average illumination of the light on the cooking surface (Emiddle): 121 lux

Sound power level at highest setting (Lwa): 64 dBA

Electrical Connection

Electrical connection rating: 101 W

Voltage: 220-240 V

Frequency (Hz): 50-60 Hz

Plug: Not present

Power supply cable length: 1500 mm

Speed 1

Extraction rate IEC 61591: 124 m³/h

Noise level IEC 60704-2-13: 44 dBA

Power: 49 W

Speed 2

Extraction rate IEC 61591: 153 m³/h

Noise level IEC 60704-2-13: 51 dBA

Power: 65 W

Speed 3

Extraction rate IEC 61591: 266 m³/h

Noise level IEC 60704-2-13: 62 dBA

Power: 96 W

Logistic Information

Dimensions of the product (mm): 133x599x510

Width: 599 mm

Depth (mm): 510 mm

Product Height (mm): 133 mm

Net weight (kg): 5.200 kg

Gross weight (kg): 6.000 kg

Packed width: 548 mm

Packaged depth: 152 mm

Height (mm) packed: 618 mm

Dimensions of the packed product (mm): 618x548x152

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 0.900 kg

Packaging composition - polystyrene (kg): 0.000 kg

Packaging composition - wood (kg): 0.000 kg

Packaging composition - plastic (kg): 0.037 kg

Optional

KITFC550

Accessories | Type: Charcoal filter | Hoods
