Hood Portofino KPF12T

Name: Hood Portofino KPF12T
Brand: Smeg
SKU: KPF12T

Product family

Hood

Hood Type

Chimney Cooker Hoods

Aesthetics

Portofino

Colour

Turquoise

Hood width

120 cm

Energy efficiency class ( EEC)

A+

Find Resellers

Compare

Highlights
Features
Accessories
Download

PORTOFINO AESTHETIC

Inspired by the rich tones of the Italian Riviera, meet Smeg's freshest design yet, perfect for contemporary living. Portofino by Smeg.

Portofino hoods are elegant and co-ordinate with the Portofino cooker range, whilst offering solid extraction and low noise levels.

Ducting or re-circulating

Most Smeg hoods offer the choice of ducting or re-circulating, so you can choose your preferred method.

Ducting out extracts cooking fumes and expels them outside, using a vent kit (available as an optional accessory) The diameter of the ducting hose should match the vent outlet of the hood (which can be found in the features tab)

SP150 - Simple vent kit for hoods with a 150mm diameter vent outlet
SP150FLAT - Comprehensive vent kit for hoods with a 150mm diameter vent outlet
SP215 - Simple vent kit for hoods with a 120mm diameter vent outlet
SP217 - Comprehensive vent kit for hoods with a 120mm diameter vent outlet

Re-circulating extracts the cooking fumes and passes them through active charcoal filters (available as an optional accessory), recirculating the cleaned air back into the room. To find out which charcoal filter your hood needs, check the accessory tab on the hoods specification.

Intensive extraction

A powerful intensive speed can be selected when quick extraction is needed, whether you’re creating a sizzling stir fry or a preparing an aromatic curry, even the strongest cooking odours will be removed in no time.

LED LIGHTING

These lights are long lasting, save money and perfectly illuminate the work surface below. They can be switched on regardless of the fans, and used simply to create ambience lighting in the kitchen.

STAINLESS STEEL FILTERS

Easy cleaning with washable stainless steel metal grease filter(s) which can be put into the dishwasher.

Aesthetics

Aesthetics: Portofino

Colour: Turquoise

Design: Chimney

Material: Stainless Steel + Painted Material

Type of steel: Brushed

Program / Functions

No. of speeds: 3

Intensive speed: Yes

Type

Product family: Hood

Hood Type: Chimney Cooker Hoods

Hood width: 120 cm

Extraction: Ducted out or re-circulation possible

EAN code: 8017709283438

Technical Features

No. of lights: 4

Light type: LED

Light power: 4 W

Light colour temperature scale (K): 4000 K

Free outlet maximum capacity: 815 m³/h

Motor power: 275 W

No. of filters: 4

Anti-grease filters: Stainless steel

Minimum distance from GAS hob: 650 mm

Minimum distance from ELECTRIC hob: 650 mm

Vent outlet: 150 mm

Non return valve: Yes

Controls

Control setting: Control knobs

Control knobs: Portofino

No. of controls: 2

Controls colour: Steel effect

Performance / Energy Label

Energy efficiency class ( EEC): A+

Fluid Dynamic Efficiency class (FDEC): A

Grease Filtering Efficiency Class (GFEC): D

Lighting Efficiency Class (LEC): A

Annual Efficiency Consumption (AEChood): 42 kWh/year

Fluid Dynamic Efficiency (FDE): 36.3

Lighting Efficiency (LE): 74.8 lux/W

Grease Filtering Efficiency (GFE): 74.9 %

Air flow at minumum speed (Qmin): 287 m³/h

Maximum extraction rate: 606 m³/h

Intensive extraction rate: 777 m³/h

Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 49 dBA

Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 67 dBA

Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost): 73 dBA

Time increase factor (F): 0.7

Energy Efficiency Index per first cavity: 41.4

Measured air flow rate at best efficiency point (Qbep): 400 m³/h

Measured air pressure at best efficiency point (Qbep): 490 Pa

Measured electric power input at best efficiency point (Wbep): 150 W

Normal Power of the light system (Wl): 4 W

Average illumination of the light on the cooking surface (Emiddle): 329 lux

Sound power level at highest setting (Lwa): 67 dBA

Electrical Connection

Nominal power: 279 W

Voltage: 220-240 V

Frequency (Hz): 50-60 Hz

Plug: No

Power supply cable length: 1000 mm

Speed 1

Extraction rate IEC 61591: 287 m³/h

Noise level IEC 60704-2-13: 49 dBA

Power: 176 W

Speed 2

Extraction rate IEC 61591: 389 m³/h

Noise level IEC 60704-2-13: 58 dBA

Power: 230 W

Speed 3

Extraction rate IEC 61591: 606 m³/h

Noise level IEC 60704-2-13: 67 dBA

Power: 260 W

Intensive speed

Extraction rate (IEC 61591): 777 m³/h

Noise level IEC 60704-2-13: 73 dBA

Power: 286 W

Logistic Information

Dimensions of the product HxWxD (mm): 1191x1196x495

Width: 1196 mm

Depth (mm): 495 mm

Product Height (mm): 1191 mm

Net weight (kg): 20.300 kg

Gross weight (kg): 28.680 kg

Packed width: 1270 mm

Packaged depth: 515 mm

Height (mm) packed: 680 mm

Dimensions of the packed product (mm): 680x1270x515

Maximum stackability: 5

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 4.377 kg

Packaging composition - polystyrene (kg): 0.843 kg

Packaging composition - wood (kg): 0.300 kg

Packaging composition - plastic (kg): 0.087 kg

Optional

Accessories, Type: Charcoal filter, Hoods

Accessories, Type: Charcoal filter, Hoods

Technical drawing

Download (png)

Instruction manual

User manual (EN) (pdf)

Other Instructions (ALL) (pdf)

Energy Label

Download (EU)

Download (UK)

Product information sheet

Download (EU)

Download (UK)

Product sheet

Download

Brochure

Download

3D file

Download

For availability in specific countries please contact your local agent
