Name: Hob Classic PM3743D
Brand: Smeg
SKU: PM3743D
Availability: outOfStock

Highlights
Features
Accessories
Download

TIMELESS DESIGN

With its strict design form, the simple classic aesthetic is timeless - fitting into a contemporary or traditional kitchen setting with ease. The range is made up of a series co-ordinating appliances finished in smart stainless steel with matching controls and handles. The collection comprises ovens, coffee machines, hobs, extractor hoods, dishwashers and wine coolers.

Mixed Fuel Hobs

For those who enjoy cooking and appreciate both gas and induction cooking, you can now have the best of both worlds. In a single hob, the mixed fuel hob combines an induction zone with traditional gas burners, offering maximum versatility of use.

90cm and 75cm widths come with an ultra-rapid gas burner and durable cast iron pan stands, accompanied by induction zones. The induction zones can be used separately or together as a single large space.

Multizone Operation

Smeg's MultiZone heating zone can be used as two independent cooking zones or combined into a single zone.

Each zone automatically adapts to the size and position of the dishes and is heated only where the pans locate, providing better heat distribution.

Fast operation

Induction allows for precise temperature control when doing intricate cooking, or simmering for example. Heat is only generated when the pan comes into direct contact of the specific cooking zone, ensuring safety in the presence of children. This helps optimise power consumption, only using the energy needed to heat the pan itself.

Induction is faster than gas cooking taking only a little over a minute to boil a pint of water. Another benefit is that any splashes will not burn onto the hob top and are easily wiped clean making it safe and user friendly.

CERAMIC GLASS

Ceramic glass is able to withstand heat above 800˚C so it is extremely robust and durable. Composed of a single glass plate measuring only 4 to 8mm, this type of glass is resistant to impact and wear.

Type

Product Family: Hob

Dimensions: 70/75 cm

Type: Mixed

Built-in: Ultra-low profile

Power supply: Mixed

EAN code: 8017709290252

Aesthetics

The slider control panel allows you to adjust the power simply by passing your finger across the touch
device.

Reinforced base: A reinforced base, developed exclusively by Smeg, consists of a steel layer fixed to the underside of the glass surface of all gas on glass hobs.

Heavy duty cast iron pan stands: for maximum stability and strength.

Colour: Black

Finishing: Glass

Aesthetics: Classic

Material: Glass

Glass Type: Eclipse ceramic

Controls colour: Steel effect

Type of control setting: Control knobs

Control knobs position: Front

No. of controls: 2

Slider: Yes

Glass edge: Straight edge

Glass on Steel: Yes

Pan stands: Cast iron

Burners: Smeg Contemporary

Burner Material: Brass

Serigraphy colour: Grey

Programs / Functions

Power booster: option allows the zone to work at full power when very intense cooking is necessary.

Total no. of cook zones: 4

No. of gas cook zones: 2

No. of induction cook zones: 2

Time-setting options: Automatic switch-off

No. of cooking zones with booster: 2

No. of Flexible zones: 1

Main on/off switch: Yes

Power levels: 9

Options

Multizone: allows several pans to be used at once, large or small, offering freedom of placement and greater flexibility

Quick selection, with one touch cooking begins at the highest level, then automatically reduces after time. Ideal for dishes that require quick boiling and then continued cooking without constant control (eg beef broth).

Timer: All ceramic hobs have a timer which automatically ends cooking after a preset time.

Time elapsed: shows how long the cooking zone has been in use.

Quick Start function: the chosen temperature is reached faster. The heating element works at maximum power until the right temperature is reached.

Child lock: some models are fitted with a device to lock the programme/cycle so it cannot be accidentally changed.

This function allows you to keep cooked food warm without burner it

Possibility to set the maximum power absorbion of the hob

All cooking zones can be reduced to the minimum power level, so the hob can be left unattended for a short period without
food overcooking or burning. Then just press again this function, the previously set power levels can be reactivated.

Standard cut out: 482-486x719-724 mm

Multizone Option: Yes

Flexible Zone Type: MultiZone

End cooking timer: 2

Pause option: Yes

Minute minder: 1

End of cooking acoustic alarm: Yes

Residual time indicator: Yes

Limited Power Consumption Mode: Yes advance

Limited Power Consumption Mode in W: 2100 a 3700 - step 100 W

Show Room Demo Option: Yes

Grill function: Yes

Control Lock / Child Safety: Yes

Keep warm automatic function: Yes

Bridge option: Yes

Quick start: Yes

Rapid level selection: Yes

Cooking zones

Ultra rapid burners: Powerful ultra rapid burners offer up to 5kw of power.

1st zone position: Front left

2nd zone position: Rear left

3rd zone position: Rear right

4th zone position: Front right

1st zone type: Gas - AUX

2nd zone type: Gas - UR

3rd zone type: Induction - Multizone

4th zone tipe: Induction - multizone

3rd zone dimensions: 24.0x18.0 cm

4th zone dimensions: 24.0x18.0 cm

Right Multizone dimension: 38.5x23.0 cm

1st zone power: 1.10 kW

2nd zone power: 3.30 kW

3rd zone power: 2.10 kW

4th zone power: 2.10 kW

Power double booster 3° zone: 3.00 kW

Power double booster 4° zone: 3.00 kW

3rd zone booster power: 2.50 kW

4th zone booster power: 2.50 kW

Booster power right Multizone: 3.60 kW

Technical Features

Overheat protection: The safety system that automatically turns off the hob in case of overheating of the control unit.

Overfill protection: The special overfill protection shuts down the stove in the presence of overflow of liquids.

Indication of residual heat: After the glass ceramic hob is switched off the residual heat indicator shows which of the heating zones still remains hot. When the temperature drops below 60 ° C, the indicator goes out.

Gas Type: G20/G25 natural gas

Automatic setting according to pan dimension: Yes

Permanent Automatic Pot Detection with indication of the relative control: Yes

Automatic pan detection: Yes

Gas safety valves: Yes

Automatic Ignition: Yes

Automatic switch off when overheat: Yes

Automatic switch off when overflow: Yes

Residual heat indicator: Yes

Protection against accidental start up: Yes

Performance / Energy Label

Energy consumption zone 3: 191 Wh/Kg

Energy consumption zone 4: 195 Wh/Kg

Electrical Connection

Gas connection rating (W): 4300 W

Nominal power (W): 3700 W

Current: 16 A

Voltage (V): 220-240 V

Voltage 2 (V): 380-415 V

Frequency (Hz): 50/60 Hz

Type of electric cable: Single phase

Power supply cable length: 120 cm

Logistic Information

Dimensions of the product HxWxD (mm): 45x750x510

Depth (mm): 510 mm

Width (mm): 750 mm

Product Height (mm): 45 mm

Net weight (kg): 15.100 kg

Gross weight (kg): 18.800 kg

Packed width: 860 mm

Packaged depth: 610 mm

Height (mm) packed: 155 mm

Dimensions of the packed product (mm): 155X860X610

Maximum stackability: 15

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 0.000 kg

Packaging composition - polystyrene (kg): 0.959 kg

Packaging composition - wood (kg): 0.000 kg

Packaging composition - plastic (kg): 0.031 kg

Accessories Included

Cast iron wok support: 1

Other gas nozzles included: G30 GPL Liquid gas

Other gas connections provided: Conical

Optional

Accessories, Type: Griddle, Cookers, Hobs

Accessories, Type: Griddle, Cookers, Hobs

Accessories, Type: Connecting strip, Hobs
