Induction hob with integrated hood 83 cm Isola Aesthetic

Energy consumption Dimensions
Find Resellers
Product code: HHSL7844MB
  • Fast cooking and precise temperature control
  • Evo Slider controls visible only when in use: an elegant touch that disappears after cooking, for a clean aesthetic
  • Automatic activation of the correct cooking zone with Autopot Detection, recognizing the pot without user intervention
  • Automatic boiling at 92°C to simplify preparations that require precision
  • Large surface created by joining two contiguous zones, perfect for large dishes - MultiZone
  • Backlit controls with white LEDs for refined aesthetics and discreet visibility
  • Dishes always served at the right temperature, even after cooking, thanks to the Keep Warm function
  • Highlights
  • Features
  • Accessories
  • Download
Accept marketing cookies to watch this video.

Aesthetics

Evolution Slider totally Back-lighted ghost effect The slider control panel allows you to adjust the power simply by passing your finger across the touch device.
Colour: Black
Finishing: Glass
Aesthetic: Isola
Glass type: Ceramic
Material: Glass
Type of control setting: EVO Slider
Control knob position: Front
Slider: Yes
LED colours: White
Glass edge: Straight edge
Frame: Yes
Frame colour: Black
Serigraphy colour: Grey

Program / Functions

Power booster: option allows the zone to work at full power when very intense cooking is necessary.
Total no. of cook zones: 4
No. of induction cook zones: 4
Time-setting options: Spegnimento automatico
No. of cooking zones with booster: 4
No. of Flexible zones: 2
Main on/off switch: Yes
Power levels: 9

Type

Product Family: Hob
Dimensions: 83 cm
Type: Induction with integrated hood
Extraction: Extraction
Built-in type: Support
Power supply: Electric
Electronic control: Yes
EAN code: 8017709351847

Technical Features

Overheat protection: The safety system that automatically turns off the hob in case of overheating of the control unit. Permanent auto pot detection Indication of residual heat: After the glass ceramic hob is switched off the residual heat indicator shows which of the heating zones still remains hot. When the temperature drops below 60 ° C, the indicator goes out. Min diameter pot detection of 9 cm
Automatic setting according to pan dimension: Yes
Permanent Automatic Pot Detection with indication of the relative control: Yes
pan detection: Yes, min 9 cm
Automatic switch off when overheat: Yes
Residual heat indicator: Yes
Protection against accidental start up: Yes

Options

Multizone: allows several pans to be used at once, large or small, offering freedom of placement and greater flexibility Quick selection, with one touch cooking begins at the highest level, then automatically reduces after time. Ideal for dishes that require quick boiling and then continued cooking without constant control (eg beef broth). Timer: All ceramic hobs have a timer which automatically ends cooking after a preset time. Time elapsed: shows how long the cooking zone has been in use. Quick Start function: the chosen temperature is reached faster. The heating element works at maximum power until the right temperature is reached. Child lock: some models are fitted with a device to lock the programme/cycle so it cannot be accidentally changed. This function allows you to keep cooked food warm without burner it Possibility to set the maximum power absorbion of the hob All cooking zones can be reduced to the minimum power level, so the hob can be left unattended for a short period without food overcooking or burning. Then just press again this function, the previously set power levels can be reactivated. Automatic Boiling function: a sensor confirms once the boiling point has been reached and then an acoustic alert signals that the ingredients can be added, saving time and energy.
Worktop Cut-Out: 490x750 mm
Multizone Option: Yes
Flexible Zone Type: MultiZone
End cooking timer: 4
Pause option: Yes
Minute minder: 1
End of cooking alarm: Yes
Residual time indicator: Yes
Limited Power Consumption Mode: Si Advance
Limited Power Consumption Mode in W: 2800, 3500, 4500, 7400 W
Showroom Demo Option: Yes
Control Lock / Child Safety: Yes
Keep warm automatic function: Yes
Cleaning option: Yes
Auto-boiling Function: Yes
Quick start: Yes
Rapid level selection: Yes

Cooking zones

1st zone position: Front-left
2nd zone position: Rear-left
3rd zone position: Rear-right
4th zone position: Front-right
1st zone type: Induction - Multizone
2nd zone type: Induction - Multizone
3rd zone type: Induction - Multizone
4th zone tipe: Induction - Multizone
1st zone dimensions: 21x19 cm
2nd zone dimensions: 21x19 cm
3rd zone dimensions: 21x19 cm
4th zone dimensions: 21x19 cm
Left Multizone dimension: 39.0x21.0 cm
Right Multizone dimension: 39.0x21.0 cm
1st zone power: 2.1 kW
2nd zone power: 2.1 kW
3rd zone power: 2.1 kW
4th zone power: 2.1 kW
1st zone booster power: 3 kW
2nd zone booster power: 3 kW
3rd zone booster power: 3 kW
4th zone booster power: 3 kW
Booster power left Multizone: 3.7 kW
Booster power right Multizone: 3.7 kW

Performance / Energy Label

Annual Efficiency Consumption (AEChood): 29 kWh/a

Electrical Connection

Plug: Not present
Electrical connection rating (W): 7600 W
Current: 34 A
Voltage (V): 220-240 V
Voltage 2 (V): 380-415 V
Frequency (Hz): 50/60 Hz
Type of electric cable supplied: Yes, Single and Double phase
Power supply cable length: 1400 cm

Standby consumption

Power consumption in stand-by mode (Ps): 0.29 W

Controls (hood)

Hood control setting: Touch Capacitive
Led color: Bianco
Display: Yes

Programs / Functions (hood)

No. of speeds: 8
Intensive speed: 2
Hood time setting: Delay
Other options: Kit for Recirculation and Extraction included
Automatic connection between integrated hood and hob: yes

Technical Features (Hood)

Free outlet maximum capacity: 650 m³/h
Motor power: 220 W
No. of filters: 1
Anti-grease filters: Alluminio
Charcoal filters included: YES, regenerable
Filter replacement indicator: Yes

Speed 1

Extraction rate IEC 61591: 220 m³/h
Noise level IEC 60704-2-13: 44 dBA
Power: 18 W

Speed 2

Extraction rate IEC 61591: 245 m³/h
Noise level IEC 60704-2-13: 47 dBA
Power: 22 W

Speed 3

Extraction rate IEC 61591: 270 m³/h
Noise level IEC 60704-2-13: 51 dBA
Power: 32 W

Speed 4

Extraction rate IEC 61591: 300 m³/h
Noise level IEC 60704-2-13: 53 dBA
Power: 40 W

Speed 5

Extraction rate IEC 61591: 340 m³/h
Noise level IEC 60704-2-13: 57 dBA
Pressure: 580 Pa
Power: 49 W

Speed 6

Extraction rate IEC 61591: 370 m³/h
Noise level IEC 60704-2-13: 59 dBA
Pressure: 590 Pa
Power: 52 W

Speed 7

Extraction rate IEC 61591: 400 m³/h
Noise level IEC 60704-2-13: 61 dBA
Pressure: 600 Pa
Power: 61 W

Speed 8

Extraction rate IEC 61591: 450 m³/h
Noise level IEC 60704-2-13: 63 dBA
Pressure: 610 Pa
Power: 75 W

Intensive speed

Extraction rate (IEC 61591): 540 m³/h
Noise level IEC 60704-2-13: 67 dBA
Power: 133 W

Intensive Speed 2

Extraction rate IEC 61591: 620 m³/h
Noise level IEC 60704-2-13: 69 dBA
Pressure: 630 Pa
Power: 210 W

Performance / Energy Label (hood)

Energy efficicency class ( EEC): A++
Fluid Dynamic Efficiency class (FDEC): A
Grease Filtering Efficiency Class (GFEC): B
Fluid Dynamic Efficiency (FDE): 37.6
Lighting Efficiency (LE): 0.0 lux/W
Grease Filtering Efficiency (GFE): 93.8 %
Air flow at minumum speed (Qmin): 220 m³/h
Air flow at maximum speed (Qmax): 450 m³/h
Air flow at boost speed (Qboost): 620 m³/h
Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 44 dBA
Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 63 dBA
Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost): 69 dBA
Time increase factor (F): 0.6
Energy Efficiency Index: 32.4
Measured air flow rate at best efficiency point (Qbep): 319 m³/h
Measured air pressure at best efficiency point (Pbep): 514 Pa
Measured electric power input at best efficiency point (Wbep): 121 W
Sound power level at highest setting (Lwa): 63 dBA

Logistic Information

Dimensions of the product (mm): 390x1125x700
Depth: 700 mm
Width: 1125 mm
Product Height: 390 mm
Net weight (kg): 18.000 kg
Gross weight (kg): 27.000 kg
Packed width: 1125 mm
Packaged depth: 700 mm
Height (mm) packed: 396 mm
Dimensions of the packed product (mm): 396X1125X700
Type of packaging: Cardboard
Packaging composition - paper & cardboard (kg): 9.000 kg
Packaging composition - polystyrene (kg): 0.000 kg
Packaging composition - wood (kg): 0.000 kg
Packaging composition - plastic (kg): 0.050 kg

Accessories included

Other accessories: Filtering kit and charcoal filter regenerable included
