Kitchen sink Standard built-in Linea Aesthetic

Dimensions
Find Resellers
Product code: LRX902
High quality AISI 304 stainless steel sink for the best performance in resistance and durability. Designed for quick and easy installation, the sink is suitable for any type of kitchen and ensures a hygienic and safe kitchen environment.
  • Possibility of having the tap hole for direct installation of the tap on the sink, for a larger and neater surface area
  • Two bowls for greater versatility and dual functionality
  • Features
  • Accessories
  • Download

Type

Product Family: Sink
Type: Welded sink
Sink material: Stainless steel
Sink dimensions: 90 cm
No. of bowls: 2
EAN code: 8017709208936

Aesthetics

Standard installation: Traditional installation in tabletop, suitable for any kitchen sets
Colour: Stainless steel
Finishing: Brushed
Aesthetic: Linea
Type of steel: AISI304
Tap hole / precut tap hole: 1 Tap hole
Building in type: Standard

Technical Features

Cupboard width required for sink installation
Width (mm): 897 mm
Frame depth (mm): 9
Undermount cutout radius: 10 mm
Frame thickness: 0.7 mm
Height from kitchen top: 10 mm
Cutout dimension topmount (mm): 860 x 480 mm
Tap hole: 1
Tap hole diameter: 35 mm
Dividing wall width: 29 mm
Gasket type: Sealing paste
No. of clips: 12
Type of clips: Standard
Base unit size: 90 cm

RH Bowl

Sink depth - depending on the model, the depth can be from13 to 24,5
Bowl type RH: Minimum radius
Bowl dimensions, WxDxH (mm): 400 x 340 x 200 mm
Bowl thickness (mm): 1 mm
Bowl depth (mm): 200 mm
Radius corner right bowl (mm): 15 mm
Overflow: Yes, flush fitted
Strainer position: Side bowl
Strainer dimension: 3.5" Steel cover

LH Bowl

Sink depth - depending on the model, the depth can be from13 to 24,5
Bowl type LH: Minimum radius
Bowl dimensions LH, WxDxA (mm): 400 x 340 x 200 mm
Bowl thickness LH (mm): 1 mm
LH Bowl depth (mm): 200 mm
Radius corner left bowl: 15 mm
Strainer position LH bowl: Side bowl
Strainer dimension LH bowl: 3.5" Steel cover

Logistic Information

Dimensions of the product (mm): 219x897x510 mm
Net weight (kg): 9.000 kg
Gross weight (kg): 11.200 kg
Depth (mm): 510 mm
Product Height (mm): 219 mm
Packed width: 1000 mm
Packaged depth: 580 mm
Height (mm) packed: 250 mm
Dimensions of the packed product (mm): 250X1000X580 mm
Type of packaging: Cardboard+supports
Packaging composition - paper & cardboard (kg): 2.040 kg
Packaging composition - polystyrene (kg): 0.220 kg
Packaging composition - wood (kg): 0.000 kg
Packaging composition - plastic (kg): 0.026 kg

Accessories Included

Accessories for installation: Strainer, Savespace siphon with dishwasher outlet connection, Fixing clips, Gasket
Rondò Cover waste kit: Yes

Optional

KITFD100
KITFD100
Accessories, Type: Waste disposal, Sinks
KITFD075
KITFD075
Accessories, Type: Waste disposal, Sinks
KITFD050
KITFD050
Accessories, Type: Waste disposal, Sinks
DB34
DB34
Accessories, Type: Basket, Sinks
3713
3713
Accessories, Type: Siphon, Sinks
CVB40N2
CVB40N2
Accessories, Type: Chopping board, Sinks
RND2V
RND2V
Accessories, Type: Rondò waste kit, Sinks
CB28QU
CB28QU
Accessories, Type: Chopping board, Sinks
STABMIX
STABMIX
Accessories, Type: Stabiliser, Sinks

Technical drawing

Download (png)

Product sheet

Download

Brochure

Download

3D file

Download
