Kitchen sink Flush fitted, Flat, Undermount built-in Universale Aesthetic VR12S3434

Product Family
Sink
Aesthetic
Universale
Type
Welded bowl
Building in type
Flush fitted, Flat, Undermount
No. of bowls
2
Colour
Stainless steel
Sink material
Stainless steel
  • Features
  • Accessories
  • Download

Type

Product Family: Sink
Type: Welded bowl
Sink material: Stainless steel
Sink dimensions: 74 cm
No. of bowls: 2
EAN code: 8017709308124

Aesthetics

Flush-fitted installation: Models of sinks/hobs which are integrated flush with the tabletop of a kitchen unit. Flat: Installation of productwith flat edge. Under table top installation: The sink is fixed under tabletop, which extends the work surface and the depth of the sink.
Colour: Stainless steel
Finishing: Brushed
Aesthetic: Universale
Series: Mira
Type of steel: AISI304
Tap hole / precut tap hole: No Taphole
Building in type: Flush fitted, Flat, Undermount

Technical Features

Cupboard width required for sink installation
Width (mm): 740 mm
Cutout dimension undermount (mm): 700*400 mm
Frame thickness: 1 mm
Height from kitchen top: 1 mm
Cutout dimension topmount (mm): 730*430 mm
Dividing wall width: 25 mm
No. of clips: 10
Type of clips: Standard + undermount clip
Base unit size: 80, 90 cm

RH Bowl

Sink depth - depending on the model, the depth can be from13 to 24,5
Bowl type RH: Minimum radius
Bowl dimensions, WxDxH (mm): 340 x 400 x 200 mm
Bowl thickness (mm): 1 mm
Bowl depth (mm): 200 mm
Radius corner right bowl (mm): 12 mm
Overflow: Yes, flush fitted
Strainer position: Wall position
Strainer dimension: 3.5"

LH Bowl

Sink depth - depending on the model, the depth can be from13 to 24,5
Bowl type LH: Minimum radius
Bowl dimensions LH, WxDxA (mm): 340 x 400 x 200 mm
Bowl thickness LH (mm): 1 mm
LH Bowl depth (mm): 200 mm
Radius corner left bowl: 12 mm
Overflow LH bowl: Yes, flush fitted
Strainer position LH bowl: Wall position
Strainer dimension LH bowl: 3.5"

Logistic Information

Dimensions of the product (mm): 201x740x440 mm
Net weight (kg): 8.280 kg
Gross weight (kg): 10.560 kg
Depth (mm): 440 mm
Product Height (mm): 201 mm
Packed width: 802 mm
Packaged depth: 492 mm
Height (mm) packed: 261 mm
Dimensions of the packed product (mm): 261X802X492 mm
Type of packaging: Cardboard
Packaging composition - paper & cardboard (kg): 2.272 kg
Packaging composition - polystyrene (kg): 0.000 kg
Packaging composition - wood (kg): 0.000 kg
Packaging composition - plastic (kg): 0.020 kg

Accessories Included

Accessories for installation: Strainer, Savespace siphon with dishwasher outlet connection, Fixing clips, Silicone
Integrated flush waste kit: Yes
