Sink

Universale

VSTR4018-2

Product Family
Sink
Aesthetics
Universale
Type
Side by side undermount bowls
Building in type
Undermount
No. of bowls
1 + 3/4
Color
Stainless steel
  • Features
  • Accessories
  • Download

Type

Product Family: Sink
Type: Side by side undermount bowls
Sink material: Stainless steel
Sink dimensions: 60 cm
No. of bowls: 1 + 3/4
EAN code: 8017709262129

Aesthetics

Color: Stainless steel
Finishing: Brushed
Aesthetics: Universale
Serie: Mira
Type of steel: AISI304
Tap hole / precut tap hole: No Taphole
Building in type
  • Under table top installation: The sink is fixed under tabletop, which extends the work surface and the depth of the sink. Undermount

Technical Features

Width (mm): 608 mm
Frame thickness: 1 mm
Cutout dimension undermount (mm): 401*551 mm
Tap hole diameter: 35 mm
Dividing wall width: 30 mm
No. of clips: 8
Type of clips: Undermount clip
Base unit size
  • Cupboard width required for sink installation 80 cm

RH Bowl

???BOWL_DEPTH_16,2cm_72dpi???
Bowl type RH: Minimum radius
Bowl dimensions, WxDxH (mm): 180 x 340 x 162 mm
Bowl thickness (mm): 1 mm
Bowl depth (mm): 162 mm
Radius corner right bowl (mm): 15 mm
Strainer position: Centre of bowl
Strainer dimension: 3.5" Steel cover

LH Bowl

Sink depth - depending on the model, the depth can be from13 to 24,5
Bowl type LH: Minimum radius
Bowl dimensions LH, WxDxA (mm): 400 x 340 x 200 mm
Bowl thickness LH (mm): 1 mm
LH Bowl depth (mm): 200 mm
Radius corner left bowl: 15 mm
Overflow LH bowl: Yes, flush fitted
Strainer position LH bowl: Centre of bowl
Strainer dimension LH bowl: 3.5" Steel cover

Logistic Information

Dimensions of the product (mm): 200x608x472 mm
