Dishwashers

Universal

DI4522

Product Family
Dishwashers
Aesthetics
Universal
Installation
Fully-integrated built-in
Width
45 cm
Colour
Black
Energy Efficiency Class (Washing cycle)
E
  • Highlights
  • Features
  • Accessories
  • Download

SwingWash System

Smeg's patented SwingWash spray system improves wash coverage in  Smeg's 45cm compact dishwashers thanks to the addition of an extra spray arm which directs water towards the corners, swinging alternately between left and right during the cycle.

INVERTER MOTOR

Some dishwasher models are fitted with a latest generation Inverter motor which guarantees a longer service life, efficiency, reduced energy consumption and noise level.

Dishwashers fitted with the Inverter Motor have a Silence program which reduces the initial noise level of the dishwasher by 2 dB (A).
This is ideal for open plan kitchens and night use, especially during off-peak hours for total discretion.

DELAY TIMER

A delay timer can be set to run the programme at a convenient time or to take advantage of off-peak energy periods.

AQUASTOP

Most Smeg dishwashers have Total acquastop, an electronic device fitted to the water intake hose and the base of the machine, which monitors water levels in the machine, detects leaks in the hose and switches off the water supply immediately directly from the source when necessary, preventing water spillages onto the floor.

SELF CLEAN PROGRAM
An automatic program designed for cleaning and maintenance of the machine.

Type

COMM_HEIGHT_82_72dpi
Product Family: Dishwashers
Commercial height: 82 cm
Installation: Fully-integrated built-in
Width: 45 cm
Kitchen panel: Not supplied
EAN code: 8017709302931

Aesthetics

Colour: Black
Finishing: Glossy Black
Aesthetics: Universal
Front panel colour: Black
Door type: Galvanized
LED/display colour: White
Buttons colour: Black

Programme / Functions

Eco: Eco, this economic wash programme uses a low amount of water and energy in order to provide the most environmentally friendly cleaning option. ???PRG_AUTO5060_72dpi??? ???PRG_EXPRESS50_72dpi??? Soak programme: The soak programme provides a rinse to prevent dirt from drying. ???PRG_MIX60_72dpi???
No. of programmes: 6
Soak: Yes
Express 50°: Yes
ECO: Yes
Self clean: Yes
Washing temperatures: 50, 60 °C
Mix 60°: Yes
Auto 50°-60°: Yes

Options

Delay Timer: The delay timer can postpone the start of the program by up to 24 hours. ???EXTREME_OPTION_72dpi???
Delay timer option: 3 hours
Extreme option: Yes

Baskets

Anti-drip: Some models of dishwashers are equipped with special polymer nozzles anti-drip, that improve the process of drying.
N° baskets: 2
Basket colour: Grey
Basket components colour: Grey
Handle: In plastic on upper and lower basket
Upper Basket: With central fixed racks
Height adjustment of the upper basket: On two levels (4 cm)
Largest loadable dish in upper basket: 20,0 cm
Lower Basket: With fixed racks
Lower basket with anti-drip inserts: Yes
Largest loadable dish in lower basket: 31,5 cm
Cutlery basket: Yes
Colour Inner Components: Grey

Technical Features

Models with new Flexi Fit hinges are able to be installed in kitchens with a plinth of just
5cms. With this new hinge design, the panel has a sliding movement from the bottom to
the top, avoiding any possible interference of the panel with the plinth. Total Acquastop: In addition to the partial Acquastop protection present in all Smeg dishwashers, some models have an electronic device fitted to the water intake hose, which monitors water levels in the machine, detects leaks in the hose and switches off the water supply immediately when necessary.
Controls: Electronic
Door opening system: Yes
On/off indicator: Yes
Salt light indicator: Light
Rinse aid indicator: Light
End of cycle indicator: Acoustic signal
Washing system: Standard
Drying system: Natural condenser drying, with Dry Assist + automatic door opening system at the end of the cycle
Motor: Inverter 2.0
Water softener: With electronic setting
Flood protection system: Total Acquastop
Water supply: Single; cold/hot water max. 60°C - energysave with hot water up to 35%
Max water hardness: 90°fH; 50°dH
Steam protection: In plastic
Tank material: Stainless steel
Filter: Stainless steel
Concealed heating element: Yes
Min. and max. frontal panel weight: 2 - 7,5 kg
Hinges: Self balancing, Sliding, FLEXIFIT
Min. and max plinth height: 40 - 175 mm
Adjustable feet: 6 cm, from 820 to 880 mm
Back feet adjustable from front: Yes

Performance / Energy Label NEW

Noise Level: Excellent insulation and special devices keep noise to a minimum. ???WATERSAVE_9_9_72dpi??? ???Energy_Classes_E_right_72dpi???
Energy Efficiency Class (Washing cycle): E
Energy consumption [per 100 cycles, based on the eco programme]: 70 KWh
Rated capacity (ps): 9
Water consumption [per cycle]: 9.9 litres
Programme duration: 4:00 h:min
Airborne acoustical noise emissions (spinning phase): 46 dB(A) re 1 pW
Airborne acoustical noise emission class: C
Energy efficiency Index (EEI) (Washing cycle): 55.9

Electrical Connection

Connected power: 1300 W
Voltage: 220-240 V
Type of connection: Single-phase
Frequency (Hz): 50 Hz
Power supply cable length: 140 cm

Logistic Information

Dimensions of the product HxWxD (mm): 818x446x550
