Induction hob with integrated hood

Glass finish Universale aesthetic

Name: Induction hob with integrated hood Glass finish Universale aesthetic
Brand: Smeg
SKU: HOBD682D2

Dimensions

Find Resellers

Compare

Product code: HOBD682D2

Advanced hobd that, thanks to cutting-edge technology, combines the functions of a hob and extractor hood in a single structure to optimise space and reduce clutter

Fast cooking and precise temperature control
Precise and versatile cooking with Multi Slider controls and white LEDs, combining functionality with minimal design
Automatic activation of the correct cooking zone with Autopot Detection, recognizing the pot without user intervention
Large surface created by joining two contiguous zones, perfect for large dishes - MultiZone
Backlit controls with white LEDs for refined aesthetics and discreet visibility
Dishes always served at the right temperature, even after cooking, thanks to the Keep Warm function
Delicate ingredients like butter or chocolate can be melted at 44°C in a controlled way

Highlights
Features
Accessories
Download

Maximum flexibility

The Multizone function combines two adjacent cooking zones into one large surface. The cooktop automatically detects the cookware and suggests the most suitable mode.

Aesthetics

Aesthetic: Universale

Colour: Black

Finishing: Glass

Glass type: Ceramic

Material: Glass

Type of control setting: Multi Slider

Control knob position: Front

Slider: Yes

LED colours: White

Glass edge: Straight edge

Pan stands: Stainless steel

Serigraphy colour: Grey

Program / Functions

Total no. of cook zones: 4

No. of induction cook zones: 4

Time-setting options: Automatic switch-off

No. of cooking zones with booster: 4

No. of Flexible zones: 2

Main on/off switch: Yes

Power levels: 9

Type

Product Family: Hob

Dimensions: 83 cm

Type: Induction with integrated hood

Extraction: Extraction

Built-in type: Ultra-low profile or Fully Flushed

Power supply: Electric

Electronic control: Yes

EAN code: 8017709341893

Technical Features

Automatic setting according to pan dimension: Yes

Permanent Automatic Pot Detection with indication of the relative control: Yes

pan detection: Yes, min. 9 cm

Automatic switch off when overflow: Yes

Residual heat indicator: Yes

Protection against accidental start up: Yes

Options

Worktop Cut-Out: 490x750 mm

Multizone Option: Yes

Flexible Zone Type: MultiZone

End cooking timer: 4

Pause option: Yes

Minute minder: 1

End of cooking alarm: Yes

Residual time indicator: Yes

Control Lock / Child Safety: Yes

Keep warm automatic function: Yes

Quick start: Yes

Simmering Function: Yes

Melting/Low temperature cooking function: Yes

Rapid level selection: Yes

Cooking zones

1st zone position: Front-left

2nd zone position: Rear-left

3rd zone position: Rear-right

4th zone position: Front-right

1st zone type: Induction - Multizone

2nd zone type: Induction - Multizone

3rd zone type: Induction - Multizone

4th zone tipe: Induction - Multizone

1st zone dimensions: 21.0x19.0 cm

2nd zone dimensions: 21.0x19.0 cm

3rd zone dimensions: 21.0x19.0 cm

4th zone dimensions: 21.0x19.0 cm

Left Multizone dimension: 46.0x21.0 cm

Right Multizone dimension: 46.0x21.0 cm

1st zone power: 2.10 kW

2nd zone power: 2.10 kW

3rd zone power: 2.10 kW

4th zone power: 2.10 kW

1st zone booster power: 3.00 kW

2nd zone booster power: 3.00 kW

3rd zone booster power: 3.00 kW

4th zone booster power: 3.00 kW

Booster power left Multizone: 3.70 kW

Booster power right Multizone: 3.70 kW

Electrical Connection

Plug: Not present

Electrical connection rating (W): 7620 W

Current: 33 A

Voltage (V): 220-240 V

Voltage 2 (V): 380-415 V

Frequency (Hz): 50/60 Hz

Type of electric cable supplied: Yes, Single and Double phase

Power supply cable length: 120 cm

Standby consumption

Power Consumption in Off mode (Po): 0.49 W

Controls (hood)

Hood control setting: Touch Capacitive

Led color: Bianco

Display: Yes

Programs / Functions (hood)

No. of speeds: 8

Intensive speed: 2

Automatic connection between integrated hood and hob: Yes

Technical Features (Hood)

Free outlet maximum capacity: 650 m³/h

Motor power: 220 W

No. of filters: 1

Anti-grease filters: Inox

Charcoal filters included: YES, regenerable

Filter replacement indicator: Yes

Speed 1

Extraction rate IEC 61591: 230 m³/h

Noise level IEC 60704-2-13: 49 dBA

Power: 40 W

Speed 2

Extraction rate IEC 61591: 270 m³/h

Noise level IEC 60704-2-13: 51 dBA

Power: 50 W

Speed 3

Extraction rate IEC 61591: 340 m³/h

Noise level IEC 60704-2-13: 55 dBA

Power: 90 W

Speed 4

Extraction rate IEC 61591: 370 m³/h

Noise level IEC 60704-2-13: 60 dBA

Power: 90 W

Speed 5

Extraction rate IEC 61591: 400 m³/h

Noise level IEC 60704-2-13: 62 dBA

Pressure: 500 Pa

Power: 100 W

Speed 6

Extraction rate IEC 61591: 435 m³/h

Noise level IEC 60704-2-13: 63 dBA

Pressure: 550 Pa

Power: 120 W

Speed 7

Extraction rate IEC 61591: 460 m³/h

Noise level IEC 60704-2-13: 65 dBA

Pressure: 600 Pa

Power: 150 W

Speed 8

Extraction rate IEC 61591: 500 m³/h

Noise level IEC 60704-2-13: 68 dBA

Pressure: 620 Pa

Power: 170 W

Intensive speed

Extraction rate (IEC 61591): 540 m³/h

Noise level IEC 60704-2-13: 70 dBA

Power: 180 W

Intensive Speed 2

Extraction rate IEC 61591: 630 m³/h

Noise level IEC 60704-2-13: 73 dBA

Pressure: 630 Pa

Power: 220 W

Performance / Energy Label (hood)

Energy efficicency class ( EEC): A+

Fluid Dynamic Efficiency class (FDEC): A

Grease Filtering Efficiency Class (GFEC): B

Fluid Dynamic Efficiency (FDE): 32.10

Lighting Efficiency (LE): 0.0 lux/W

Grease Filtering Efficiency (GFE): 85.1 %

Air flow at minumum speed (Qmin): 230 m³/h

Air flow at maximum speed (Qmax): 500 m³/h

Air flow at boost speed (Qboost): 630 m³/h

Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 49 dBA

Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 68 dBA

Airbourne acoustical A-weighted sound power emission at boost speed (SPEboost): 73 dBA

Time increase factor (F): 0.8

Energy Efficiency Index: 44.2

Measured air flow rate at best efficiency point (Qbep): 359 m³/h

Measured air pressure at best efficiency point (Pbep): 549 Pa

Measured electric power input at best efficiency point (Wbep): 139 W

Sound power level at highest setting (Lwa): 68 dBA

Electrical Connections (hood)

Frequenza cappa: 50-60 Hz

Logistic Information

Dimensions of the product (mm): 210x830x520 mm

Depth: 520 mm

Width: 830 mm

Product Height: 210 mm

Net weight (kg): 18.000 kg

Gross weight (kg): 25.000 kg

Packed width: 1020 mm

Packaged depth: 760 mm

Height (mm) packed: 480 mm

Dimensions of the packed product (mm): 480x1020x760 mm

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 7.250 kg

Packaging composition - polystyrene (kg): 0.000 kg

Packaging composition - wood (kg): 0.000 kg

Packaging composition - plastic (kg): 0.118 kg

Accessories included

Other accessories: Filtering kit and charcoal filter regenerable included

Optional

Accessories, Type: Exhaust kit, Hobs

Accessories, Type: Recirculating kit, Hobs, Hoods

Accessories, Type: Recirculating kit, Hobs

Accessories, Type: Tube kit, Hobs, Hoods

Accessories, Type: Charcoal filter, Hobs

Accessories, Type: Charcoal filter, Hobs

Accessories, Type: Pan stands, Hoods

Accessories, Type: Pan stands, Hoods

Accessories, Type: Pan stands, Hoods

Accessories, Type: Pan stands, Hoods

Accessories, Type: Grill, Cookers, Hobs

Accessories, Type: Grill, Cookers, Hobs

Technical drawing

Download (png)

Instruction manual

User manual (EN) (pdf)

Installation Manual (ALL) (pdf)

Energy Label

Download

Product information sheet

Download

Product sheet

Download

Brochure

Download
