Decorative wall hood

90 cm Universale Aesthetic

Name: Decorative wall hood 90 cm Universale Aesthetic
Brand: Smeg
SKU: KATE900CEX

Energy consumption Dimensions

Find Resellers

Compare

Product code: KATE900CEX

T-Shape wall hood model 90 cm, with a contemporary design and elegant lines. It offers powerful and silent suction, adding a touch of style to the environment. Built with high-quality materials, it ensures long-lasting performance and a less odorous environment

Highlights
Features
Accessories
Download

Charcoal filters

Fundamental components of the filter hood, the activated carbon filters guarantee the absorption of fats and vapors and a perfect elimination of odors.

Aesthetics

Aesthetic: Universale

Colour: Stainless steel

Design: T flat

Finishing: Satin

Material: Stainless steel

Type of steel: Brushed

Program / Functions

No. of speeds: 3

Type

Product family: Hood

Hood Type: Decorative wall hood

Hood width: 90 cm

Extraction: Extraction

EAN code: 8017709255060

Technical Features

No. of lights: 2

Light type: LED

Light Power: 2.5 W

Light color temperature scale (K): 3500 K

Free outlet maximum capacity: 612 m³/h

Motor power: 175 W

No. of filters: 3

Anti-grease filters: Aluminium

Charcoal filters included: Yes

Filter replacement indicator: Yes

Minimum distance from GAS hob: 650 mm

Minimum distance from ELECTRIC hob: 500 mm

Vent outlet: 150 mm

Non return valve: Yes

Controls

Control setting: Buttons

Performance / Energy Label

Energy efficicency class (EEC): C

Fluid Dynamic Efficiency class (FDEC): C

Grease Filtering Efficiency Class (GFEC): C

Lighting Efficiency Class (LEC): A

Annual Efficiency Consumption (AEChood): 77 kWh/a

Fluid Dynamic Efficiency (FDE): 20.2

Lighting Efficiency (LE): 76.1 lux/W

Grease Filtering Efficiency (GFE): 76 %

Air flow at minumum speed (Qmin): 240 m³/h

Air flow at maximum speed (Qmax): 581 m³/h

Airbourne acouistical A-weighted sound Power Emission at minimum speed (SPEmin): 47 dBA

Airborne acoustical A-weighted sound Power Emission at maximum speed (SPEmax): 68 dBA

Time increase factor (F): 1.3

Measured air flow rate at best efficiency point (Qbep): 336 m³/h

Measured air pressure at best efficiency point (Pbep): 334 Pa

Measured electric power input at best efficiency point (Wbep): 155 W

Nominal Power consumption of the light system (WL): 5 W

Average illumination of the light on the cooking surface (Emiddle): 381 lux

Sound power level at highest setting (Lwa): 68 dBA

Electrical Connection

Electrical connection rating: 180 W

Voltage: 220-240 V

Frequency (Hz): 50-60 Hz

Plug: Not present

Power supply cable length: 1500 mm

Speed 1

Extraction rate IEC 61591: 241 m³/h

Noise level IEC 60704-2-13: 46 dBA

Power: 110 W

Speed 2

Extraction rate IEC 61591: 370 m³/h

Noise level IEC 60704-2-13: 56 dBA

Power: 137 W

Speed 3

Extraction rate IEC 61591: 590 m³/h

Noise level IEC 60704-2-13: 68 dBA

Power: 137 W

Logistic Information

Dimensions of the product (mm): 540x898x450

Width: 898 mm

Depth (mm): 450 mm

Product Height (mm): 540 mm

Net weight (kg): 13.000 kg

Gross weight (kg): 16.800 kg

Packed width: 945 mm

Packaged depth: 374 mm

Height (mm) packed: 576 mm

Dimensions of the packed product (mm): 576x945x374

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 3.656 kg

Packaging composition - polystyrene (kg): 0.138 kg

Packaging composition - wood (kg): 0.000 kg

Packaging composition - plastic (kg): 0.018 kg

Optional

Accessories, Type: Charcoal filter, Hoods

Accessories, Type: Charcoal filter, Hoods

Technical drawing

Download (png)

Instruction manual

User manual (ALL) (pdf)

Energy Label

Download

Product information sheet

Download

Product sheet

Download

Brochure

Download
