Ceramic Hob 60 cm Universale Aesthetic SE264TD1

Product Family

Hob

Type

Ceramic

Dimensions

60 cm

Colour

Black

Built-in type

Ultra-low profile or Fully Flushed

Ceramic Hob Smeg_1

Ceramic Hob Smeg_2

Ceramic Hob Smeg_3

Ceramic Hob Smeg_4

Ceramic Hob Smeg_5

Compare

Features
Accessories
Download

Type

Glass ceramic: The base of the hob is made glass ceramic. Heating is performed by the heating elements Hi-Light.

Product Family: Hob

Dimensions: 60 cm

Type: Ceramic

Built-in type: Ultra-low profile or Fully Flushed

Power supply: Electric

EAN code: 8017709312039

Programs / Functions

Total no. of cook zones: 4

No. of ceramic cook zones: 4

Main on/off switch: Yes

Power levels: 9

Aesthetics

Colour: Black

Finishing: Glass

Aesthetic: Universale

Glass type: Ceramic

Material: Glass

Type of control setting: Digi Touch

Control knob position: Front

LED colours: Red

Glass edge: Straight edge

Serigraphy colour: Grey

Options

Timer: All ceramic hobs have a timer which automatically ends cooking after a preset time.

Time elapsed: shows how long the cooking zone has been in use.

Child lock: some models are fitted with a device to lock the programme/cycle so it cannot be accidentally changed.

Worktop Cut-Out: 490x560 mm

End cooking timer: 4

Minute minder: 1

End of cooking alarm: Yes

Residual time indicator: Yes

Showroom Demo Option: Yes

Control Lock / Child Safety: Yes

Cooking zones

1st zone position: Rear-left

2nd zone position: Front-left

3rd zone position: Rear-right

4th zone position: Front-right

1st zone type: Ceramic - Single

2nd zone type: Ceramic - Single

3rd zone type: Ceramic - Single

4th zone tipe: Ceramic - Single

1st zone dimensions: Ø 21.0 cm

2nd zone dimensions: Ø 14,5 cm

3rd zone dimensions: Ø 18.0 cm

4th zone dimensions: Ø 14.5 cm

1st zone power: 2.10 kW

2nd zone power: 1.20 kW

3rd zone power: 1.80 kW

4th zone power: 1.20 kW

Technical Features

Overheat protection: The safety system that automatically turns off the hob in case of overheating of the control unit.

Overfill protection: The special overfill protection shuts down the stove in the presence of overflow of liquids.

Indication of residual heat: After the glass ceramic hob is switched off the residual heat indicator shows which of the heating zones still remains hot. When the temperature drops below 60 ° C, the indicator goes out.

Automatic switch off when overheat: Yes

Automatic switch off when overflow: Yes

Residual heat indicator: Yes

Performance / Energy Label

Hob energy consumption: 190.1 Wh/Kg

1st zone energy consumption: 187.6 Wh/Kg

2nd zone energy consumption: 190.3 Wh/Kg

Energy consumption zone 3: 192.3 Wh/Kg

Energy consumption zone 4: 190.3 Wh/Kg

Electrical Connection

Plug: Not present

Electrical connection rating (W): 6300 W

Current: 27 A

Voltage (V): 220-240 V

Voltage 2 (V): 380-415 V

Frequency (Hz): 50/60 Hz

Type of electric cable installed: Yes, Single and Double phase

Power supply cable length: 130 cm

Logistic Information

Dimensions of the product (mm): 63x600x510

Depth: 510 mm

Width: 600 mm

Product Height: 63 mm

Net weight (kg): 7.900 kg

Gross weight (kg): 8.800 kg

Packed width: 650 mm

Packaged depth: 545 mm

Height (mm) packed: 100 mm

Dimensions of the packed product (mm): 100X650X545

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 0.522 kg

Packaging composition - polystyrene (kg): 0.340 kg

Packaging composition - wood (kg): 0.000 kg

Packaging composition - plastic (kg): 0.000 kg

Optional

SCRP

Accessories, Type: Scraper, Cookers, Hobs

Technical drawing

Instruction manual

User manual (EN) (pdf)

Product information sheet

Download

Product sheet

Download

Brochure

Download
