Induction hob

Glass effect Universale aesthetic

Name: Induction hob Glass effect Universale aesthetic
Brand: Smeg
SKU: SI1B2742D

Energy consumption Dimensions

Find Resellers

Compare

Product code: SI1B2742D

75 cm Induction hob with 1 Bridge zone: ideal for large cookware, offering flexibility and practicality with an intuitive interface

Fast cooking and precise temperature control
Immediate access to functions via touch display, for simple and intuitive control
Energy consumption optimization with Eco-Logic Advance, allowing absorption limitation from 2.4 kW in 0.1 kW steps
Large surface created by merging two adjacent zones, ideal for large dishes - Bridge Flexible Zone
Nine power levels and Boost function for optimal cooking performance
Brightness and elegance in the kitchen: the acid-etched glass gives the surface a refined, modern look that enhances the space
Stability and design even up to 700 °C: the cooktop material resists high temperatures without deforming, maintaining aesthetics and functionality even with intensive use

Features
Accessories
Download

Aesthetics

Aesthetic: Universale

Colour: Black

Finishing: Glass

Glass type: Ceramic

Material: Glass

Type of control setting: Digi Touch

Control knob position: Front

LED colours: Red

Glass edge: Straight edge

Serigraphy colour: Grey

Program / Functions

Total no. of cook zones: 4

No. of induction cook zones: 4

Time-setting options: Spegnimento automatico

No. of cooking zones with booster: 4

No. of Flexible zones: 1

Main on/off switch: Yes

Power levels: 9

Type

Product Family: Hob

Dimensions: 70/75 cm

Type: Induction

Built-in type: Ultra-low profile or Fully Flushed

Power supply: Electric

EAN code: 8017709339692

Technical Features

Automatic setting according to pan dimension: Yes

pan detection: Yes, min. 9 cm

Minimum pan diameter indication: Yes

Automatic switch off when overheat: Yes

Residual heat indicator: Yes

Protection against accidental start up: Yes

Options

Worktop Cut-Out: 478-482x555-560 mm

Flexible Zone Type: Bridge

End cooking timer: 4

Minute minder: 1

End of cooking alarm: Yes

Residual time indicator: Yes

Limited Power Consumption Mode: Yes

Limited Power Consumption Mode in W: 1000, 1600, 2200, 2800, 3500, 6000, 7200 W

Control Lock / Child Safety: Yes

Cooking zones

1st zone position: Front-left

2nd zone position: Rear-left

3rd zone position: Rear-right

4th zone position: Front-right

1st zone type: Induction - Single

2nd zone type: Induction - Single

3rd zone type: Induction - Single

4th zone tipe: Induction - Single

1st zone dimensions: Ø 18.0 cm

2nd zone dimensions: Ø 18.0 cm

3rd zone dimensions: Ø 21.0 cm

4th zone dimensions: Ø 14.5 cm

Left Bridge dimension: 38.5x18.0 cm

1st zone power: 1.50 kW

2nd zone power: 1.50 kW

3rd zone power: 1.50 kW

4th zone power: 1.20 kW

1st zone booster power: 2.00 kW

2nd zone booster power: 2.00 kW

3rd zone booster power: 2.00 kW

4th zone booster power: 1.60 kW

Performance / Energy Label

Hob energy consumption: 190.5 Wh/Kg

1st zone energy consumption: 187 Wh/Kg

2nd zone energy consumption: 187 Wh/Kg

Energy consumption zone 3: 187 Wh/Kg

Energy consumption zone 4: 201 Wh/Kg

Electrical Connection

Plug: Not present

Electrical connection rating (W): 7200 W

Current: 32 A

Voltage (V): 220-240 V

Voltage 2 (V): 380-415 V

Frequency (Hz): 50/60 Hz

Additional connection modalities: Yes, Double and Three Phase

Type of electric cable installed: Yes, Single phase

Power supply cable length: 120 cm

Standby consumption

Power off activation time: 1 min

Logistic Information

Dimensions of the product (mm): 56x750x510 mm

Depth: 510 mm

Width: 750 mm

Product Height: 56 mm

Net weight (kg): 9.700 kg

Gross weight (kg): 12.000 kg

Packed width: 835 mm

Packaged depth: 575 mm

Height (mm) packed: 130 mm

Dimensions of the packed product (mm): 130x835x575 mm

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 2.328 kg

Packaging composition - polystyrene (kg): 0.000 kg

Packaging composition - wood (kg): 0.000 kg

Packaging composition - plastic (kg): 0.010 kg

Optional

Accessories, Type: Scraper, Cookers, Hobs

Accessories, Type: Grill, Cookers, Hobs

Accessories, Type: Grill, Cookers, Hobs

Technical drawing

Download (png)

Instruction manual

User manual (EN) (pdf)

Warranty

Warranty certificate (EN) (pdf)

Product information sheet

Download

Product sheet

Download

Brochure

Download
