Induction hob

Glass effect Universale aesthetic

Name: Induction hob Glass effect Universale aesthetic
Brand: Smeg
SKU: SI1M5633D1

Energy consumption Dimensions

Find Resellers

Compare

Product code: SI1M5633D1

60 cm Induction hob with 1 Multizone: compactness and high performance with intuitive touch interface management

Fast cooking and precise temperature control
Immediate access to functions via touch display, for simple and intuitive control
Automatic activation of the correct cooking zone with Autopot Detection, recognizing the pot without user intervention
Large surface created by joining two contiguous zones, perfect for large dishes - MultiZone
Even heat distribution with the grill function, requiring just two minutes of preheating for perfectly grilled dish
Dishes always served at the right temperature, even after cooking, thanks to the Keep Warm function
Extreme flexibility with 17 power levels for accurate temperature control

Highlights
Features
Accessories
Download

Grill function

The grill function is specially designed to distribute heat evenly over the entire cooking surface. Simply select the dedicated function and place the grill on the left-hand side of the hob to obtain perfectly grilled meat, fish and vegetables with just two minutes of pre-heating the griddle.

Timer setting

Thanks to the timer function, you can adjust the cooking time effortlessly after selecting the temperature, using the easy-to-use slider for precise and perfect results.

Multizone

In addition to their sleek aesthetics and contemporary design, Smeg induction hobs are equipped with innovative technologies. The Multizone function guarantees maximum flexibility in the use of the hob and endless cooking possibilities, expanding the cooking area to suit the shape and size of different pans.

Aesthetics

Aesthetic: Universale

Colour: Black

Finishing: Glass

Glass type: Ceramic

Material: Glass

Type of control setting: Compact Lite

Control knob position: Front

Slider: Yes

LED colours: Red

Glass edge: Straight edge

Serigraphy colour: Grey

Program / Functions

Total no. of cook zones: 3

No. of induction cook zones: 3

Time-setting options: Spegnimento automatico

No. of cooking zones with booster: 3

No. of Flexible zones: 1

Main on/off switch: Yes

Power levels: 17

Type

Product Family: Hob

Dimensions: 60 cm

Type: Induction

Built-in type: Ultra-low profile or Fully Flushed

Power supply: Electric

EAN code: 8017709338046

Technical Features

Automatic setting according to pan dimension: Yes

Permanent Automatic Pot Detection with indication of the relative control: Yes

pan detection: Yes, min. 9 cm

Automatic switch off when overheat: Yes

Automatic switch off when overflow: Yes

Eco-Heat: Yes

Residual heat indicator: Yes

Protection against accidental start up: Yes

Options

Worktop Cut-Out: 478-482x555-560 mm

Double Booster: Yes

Multizone Option: Yes

Flexible Zone Type: MultiZone

End cooking timer: 3

Pause option: Yes

Minute minder: 1

End of cooking alarm: Yes

Residual time indicator: Yes

Limited Power Consumption Mode: Si Advance

Limited Power Consumption Mode in W: 2400 a 7400 - step 100 W

Showroom Demo Option: Yes

Grill function: Yes

Control Lock / Child Safety: Yes

Keep warm automatic function: Yes

Cleaning option: Yes

Quick start: Yes

Rapid level selection: Yes

Cooking zones

1st zone position: Front-left

2nd zone position: Rear-left

3rd zone position: Centre-right

1st zone type: Induction - Single

2nd zone type: Induction - Single

3rd zone type: Induction - Single

1st zone dimensions: Ø 19.5 cm

2nd zone dimensions: Ø 19.5 cm

3rd zone dimensions: Ø 28.0 cm

Left Multizone dimension: 39.0x22.0 cm

1st zone power: 2.10 kW

2nd zone power: 2.10 kW

3rd zone power: 2.8 kW

Power double booster 1° zone: 3000 kW

Power double booster 2° zone: 3000 kW

1st zone booster power: 2.50 - 3.00 kW

2nd zone booster power: 2.50 - 3.00 kW

3rd zone booster power: 3.6 kW

Booster power left Multizone: 3700 kW

Performance / Energy Label

Hob energy consumption: 190.3 Wh/Kg

1st zone energy consumption: 193 Wh/Kg

2nd zone energy consumption: 193 Wh/Kg

Energy consumption zone 3: 185 Wh/Kg

Electrical Connection

Plug: Not present

Electrical connection rating (W): 7400 W

Current: 33 A

Voltage (V): 220-240 V

Voltage 2 (V): 380-415 V

Frequency (Hz): 50/60 Hz

Additional connection modalities: Yes, Double and Three Phase

Type of electric cable installed: Yes, Single phase

Power supply cable length: 120 cm

Standby consumption

Power off activation time: 1 min

Logistic Information

Dimensions of the product (mm): 53x600x510 mm

Depth: 510 mm

Width: 600 mm

Product Height: 53 mm

Net weight (kg): 7.000 kg

Gross weight (kg): 10.500 kg

Packed width: 700 mm

Packaged depth: 620 mm

Height (mm) packed: 110 mm

Dimensions of the packed product (mm): 110x700x620 mm

Type of packaging: Cardboard

Packaging composition - paper & cardboard (kg): 3.435 kg

Packaging composition - polystyrene (kg): 0.000 kg

Packaging composition - wood (kg): 0.000 kg

Packaging composition - plastic (kg): 0.028 kg

Optional

Accessories, Type: Scraper, Cookers, Hobs

Accessories, Type: Grill, Cookers, Hobs

Accessories, Type: Grill, Cookers, Hobs

Technical drawing

Download (png)

Instruction manual

User manual (EN) (pdf)

Warranty

Warranty certificate (EN) (pdf)

Product information sheet

Download

Product sheet

Download

Brochure

Download
